1. Shaft ends multi seal protection and air purge seal protection to efficiently prevent leakage.
2. Unique mixer monitoring system to monitor working conditions of gearbox, discharge door, pump, and electronic lubrication pump.
3. Multi-pipe water spraying system to ensure even water distribution and increase spray service area.
4. With DC 24V grease pump system special for concrete mixer, self-programmed running time, water-proof, dust-proof, super performance.
5. Reinforced gearbox processed with military materials by high-precision technology , high load capacity and longer service life.
6. High-quality and resistant alloy arm, the service life is 3 - 5 times more than normally arm.
7. Optional filtering cooling system, grease-free and water-cooling shaft end sealing system, camera system, high pressure washing system, weighing system and microwave moisture monitoring system.
8. Optional capacity ranged from 1.5 cu.m to 10.0 cu.m.
| Model | Dry filling capacity (L) | Compacted yield (L) |
Mixing blades (PCS) |
Mixing motor & power (KW) | Weight (T) |
| MAO2250/1500 | 2250 | 1500 | 12 | 2×30 | 6.5 |
| MAO3000/2000 | 3000 | 2000 | 14 | 2×37 | 7.5 |
| MAO3750/2500 | 3750 | 2500 | 16 | 2×45 | 8.4 |
| MAO4500/3000 | 4500 | 3000 | 16 | 2×55 | 9.2 |
| MAO5250/3500 | 5250 | 3500 | 18 | 2×55 | 9.7 |
| MAO6000/4000 | 6000 | 4000 | 20 | 2×75 | 12 |
| MAO6750/4500 | 6750 | 4500 | 22 | 2×75 | 12.5 |
| MAO7500/5000 | 7500 | 5000 | 20 | 2×90 | 15 |
Note: All features, functionality and other product specifications are subject to change without notice or obligation.
