1. Suitable for mixing high degree of pure concrete. It’s the best choice for blocks and precast industry.
2. Dual modes of discharge door opening: hydraulic operated/manual operated, multi adjustable stopping positions.
3. For the discharge door, three directions optional, more than two openings at the same time possible.
4. More compact than the same size of twin shaft mixer, easier for plant design.
5. Optional skip hoist for aggregate feeding, weighing system and microwave moisture monitoring system.
6. Optional capacity ranged from 0.375 to 3 cubic meters per batch.
| Model | Dry filling capacity (L) | Compacted yield (L) | Mixing motor & power (KW) | Long outer arms (PCS) | Short outer arms (PCS) |
Mixing arms (PCS) |
Peripheral blades (PCS) |
Mixing blades (PCS) |
Weight (T) |
| MPC565/375 | 565 | 375 | 15 | 1 | 0 | 3 | 3 | 3 | 1.4 |
| MPC750/500 | 750 | 500 | 22 | 1 | 1 | 3 | 4 | 3 | 2.4 |
| MPC1125/750 | 1125 | 750 | 37 | 1 | 1 | 3 | 4 | 3 | 3 |
| MPC1500/1000 | 1500 | 1000 | 45 | 1 | 1 | 3 | 4 | 3 | 4 |
| MPC1875/1250 | 1875 | 1250 | 45/55 | 1 | 1 | 6 | 4 | 3+3 | 5 |
| MPC2250/1500 | 2250 | 1500 | 2×37 | 1 | 1 | 6 | 4 | 3+3 | 6.3 |
| MPC3000/2000 | 3000 | 2000 | 2×45/55 | 1 | 1 | 6 | 8 | 3+3 | 8.5 |
| MPC4500/3000 | 4500 | 3000 | 2×45/55 | 3 | 0 | 9 | 9 | 3+3+3 | 16 |
Note: All features, functionality and other product specifications are subject to change without notice or obligation.
